Plain Bearing Blocks
Great performance in applications with heavy and static loads.
Technical features
- Acetal sheave.
- Stainless steel strap for best strength and longer service life.
- Stiff glass fibre reinforced composite cheeks to prevent lines from wedging.
- Sliding swivel locking mechanism.
Specifications 40mm
| Weight: 95.00 g Safe working Load: 350 kg Breaking Load: 700 kg Max line size: 8 mm Block type: fiddle |
Specifications 50mm
| Weight: 170.00 g Safe working Load: 650 kg Breaking Load: 1300 kg Max line size: 12 mm Shackle diam: 5 mm |
Specifications 60mm
| Weight: 333.00 g Safe working Load: 1000 kg Breaking Load: 2000 kg Max line size: 14 mm Shackle diam: 6 mm |
